Gas powered
FSAE Michigan May 2023: 1st Overall
ENGINE: Yamaha YZF-R6 with Bosch ETC
FRAME: Hybrid monocoque, AL honeycomb and CFRP tub with 4130 Rear Subframe
DRIVE: RWD
BRAKE: Wilwood GP200 and AP CP4226 Calipers, Crossdrilled AR500 Floating Rotors
FUEL SYSTEM: Stock Yamaha
ELECTRONICS: Bosch MS6.2 ECU, Motec PDM, custom Gear Control Module
FUEL TYPE: 93 Octane
COOLING: 16.5kW heat rejection rate custom radiator and Davies, Craig EWP80 Pump
MPD: 11000 rpm
BSCD: 67mm bore/ 42.5 mm stroke/ 599cc/13.1compression
MPT: 9500 rpm
SUSPENSION: Roll-heave Decoupled, MultimaticDSSVDampers, Double A-Arm, Pushrod Actuated
FR/RR TRACK: 49in front, 49in rear
TIRE: Hoosier 16x7.5-10 R20 on 10" OZMagnesium Center-Locking Rims
WEIGHT: 440 lbs with 150lb driver
OLWH: L: 3109mm / W: 1468mm / H: 1124mm
WHEELBASE: 60in
UNIQUE: Roll-Heave Decoupled Suspension, New Frame, Driver Compliance Study
FSAE Michigan May 2022: 1st Overall
FSAE Michigan June 2022: 1st Overall
ENGINE: Yamaha YZF-R6
FRAME: Carbon Fiber Hybrid Monocoque with 4130 Steel Rear Spaceframe
DRIVE: RWD
BRAKE: Wildwood 2-piston front, AP Racing 2-piston rear
FUEL SYSTEM: Stock Yamaha
ELECTRONICS: Bosch MS6.2 ECU, Motec PDM, custom Gear Control Module
FUEL TYPE: 93 Octane
COOLING: Vertically mounted single core double pass radiator, 960 CFM fan
MPD: 10500 rpm
BSCD: 67mm bore/ 42.5 mm stroke/ 599cc/13.1compression
MPT: 9000 rpm
SUSPENSION: Double unequal length A-arms, Ohlins TTX25 MkII dampers
FR/RR TRACK: 49in front, 49in rear
TIRE: Hoosier 16x7.5-13 LC0
WEIGHT: 440 lbs with 150lb driver
OLWH: L: 3109mm / W: 1468mm / H: 1124mm
WHEELBASE: 62in
UNIQUE: Custom airfoils, custom CFRP steering wheel, position adjustable CFRP seat
Knowledge Event 2021: 1st Overall
FSAE Las Vegas 2021: 3rd Overall
FSAE Michigan 2021: 2nd Overall
ENGINE: Yamaha YZF-R6
FRAME: Carbon Fiber Hybrid Monocoque with 4130 Steel Rear Spaceframe
DRIVE: RWD
BRAKE: Brembo 2-piston front and rear
FUEL SYSTEM: Stock Yamaha
ELECTRONICS: Bosch MS6.2 ECU, Motec PDM, custom Gear Control Module
FUEL TYPE: 93 Octane
COOLING: Vertically mounted single core double pass radiator, 750 CFM fan
MPD: 10500 rpm
BSCD: 67mm bore/ 42.5 mm stroke/ 599cc
MPT: 9000 rpm
SUSPENSION: Double unequal length A-arms, Ohlins TTX25 MkII dampers
FR/RR TRACK: 49in front, 49in rear
TIRE: Goodyear D2704 20.0x7.0-13
WEIGHT: 470 lbs with 150lb driver
OLWH: L: 3109mm / W: 1468mm / H: 1124mm
WHEELBASE: 64in
UNIQUE: Custom airfoils, custom CFRP steering wheel, custom PDM
FSAE Michigan 2019: 17th Overall
FSAE Lincoln 2019: 34th Overall
ENGINE: Yamaha YZF-R6
FRAME: Carbon Fiber Hybrid Monocoque with 4130 Steel Rear Spaceframe
DRIVE: RWD
BRAKE: Brembo 4-piston front, 2-piston rear
FUEL SYSTEM: Stock Yamaha
ELECTRONICS: Motec M400 ECU and student designed data acquisition
FUEL TYPE: 93 Octane
COOLING: Vertically mounted single core double pass radiator, 1221 cfm fan
MPD: 10500 rpm
BSCD: 67mm bore / 42.5mm stroke / 599cc
MPT: 9000 rpm
SUSPENSION: Double unequal length A-arms, Ohlins TTX25 MkII dampers
FR/RR TRACK: 49in front, 49in rear
TIRE: Goodyear D2704 20.0x7.0-13
WEIGHT: 575 lbs with 150lb driver
OLWH: L: 3109mm / W: 1468mm / H: 1124mm
WHEELBASE: 64in
UNIQUE: Custom airfoils, custom CFRP steering wheel, custom PDM
FSAE Michigan 2018: 50th Overall
FSAE Lincoln 2018: 34th Overall
ENGINE: Yamaha YZF-R6
FRAME: Carbon Fiber Hybrid-Monocoque with 4130 Rear Spaceframe
DRIVE: RWD
BRAKE: Brembo 4-piston front, 2-piston rear
FUEL SYSTEM: Stock Yamaha
ELECTRONICS: Motec M400 ECU and student designed data acquisition
FUEL TYPE: 93 Octane
COOLING: Vertically mounted single core double pass radiator, 1221 cfm fan
MPD: 10500 rpm
BSCD: 67mm bore / 42.5mm stroke / 599cc
MPT: 9000 rpm
SUSPENSION: Double unequal length A-arms, Ohlins TTX25 MkII dampers
FR/RR TRACK: 49in front, 49in rear
TIRE: Goodyear D2704 20.0x7.0-13
WEIGHT: 590 lbs with 150lb driver
OLWH: L: 3109mm / W: 1468mm / H: 1124mm
WHEELBASE: 64in
UNIQUE: Custom airfoils, custom CFRP steering wheel, custom PDM
FSAE Michigan 2017: 15th Overall
FSAE Lincoln 2017: 6th Overall
ENGINE: Yamaha YZF-R6
FRAME: 4130 Steel Space Frame
DRIVE: RWD
BRAKE: AP Racing 4-piston front, 2-piston rear
FUEL SYSTEM: Stock Yamaha
ELECTRONICS: Motec M400 ECU and student designed data acquisition
FUEL TYPE: 93 Octane
COOLING: Vertically mounted single core double pass radiator, 1221 cfm fan
MPD: 10500 rpm
BSCD: 67mm bore / 42.5mm stroke / 599cc
MPT: 9000 rpm
SUSPENSION: Double unequal length A-arms, Ohlins TTX25 MkII dampers
FR/RR TRACK: 49in front, 49in rear
TIRE: Goodyear D2704 20.0x7.0-13
WEIGHT: 580 lbs with 150lb driver
OLWH: L: 3109mm / W: 1468mm / H: 1124mm
WHEELBASE: 64in
UNIQUE: Custom airfoils, custom CFRP steering wheel, custom PDM
FSAE Michigan 2016: 28th Overall
FSAE Lincoln 2016: 21st Overall
ENGINE: Honda CBR600 F4i
FRAME: 4130 Steel Space Frame
DRIVE: RWD
BRAKE: AP Racing 4-piston front, 2-piston rear
FUEL SYSTEM: Stock Honda
ELECTRONICS: Motec M400 ECU and student designed data acquisition
FUEL TYPE: 93 Octane
COOLING: Vertically mounted single core double pass radiator, 1221 cfm fan
MPD: 10500 rpm
BSCD: 67mm bore / 42.5mm stroke / 599cc
MPT: 9000 rpm
SUSPENSION: Double unequal length A-arms, Ohlins TTX25 MkII dampers
FR/RR TRACK: 49in front, 49in rear
TIRE: Hoosier R25B 20.0x7.0-13
WEIGHT: 620 lbs with 150lb driver
OLWH: L: 3109mm / W: 1468mm / H: 1124mm
WHEELBASE: 64in
UNIQUE: Custom airfoils, custom CFRP steering wheel, custom PDM
FSAE Michigan 2015: 47th Overall
FSAE Lincoln 2015: 3rd Overall
ENGINE: Honda CBR600 F4i
FRAME: 4130 Steel Space Frame
DRIVE: RWD
BRAKE: AP Racing 4-piston front, 2-piston rear
FUEL SYSTEM: Stock Honda
ELECTRONICS: Motec M400 ECU and student designed data acquisition
FUEL TYPE: 93 Octane
COOLING: Vertically mounted single core double pass radiator, 1221 cfm fan
MPD: 10500 rpm
BSCD: 67mm bore / 42.5mm stroke / 599cc
MPT: 9000 rpm
SUSPENSION: Double unequal length A-arms, Ohlins TTX25 MkII dampers
FR/RR TRACK: 49in front, 49in rear
TIRE: Hoosier R25B 20.0x7.0-13
WEIGHT: 620 lbs with 150lb driver
OLWH: L: 3109mm / W: 1468mm / H: 1124mm
WHEELBASE: 64in
UNIQUE: Custom airfoils, custom CFRP steering wheel, custom PDM
FSAE Michigan 2014: 17th Overall
FSAE Lincoln 2014: 33rd Overall
ENGINE: Honda CBR600 F4i
FRAME: 4130 Steel Space Frame
DRIVE: RWD
BRAKE: AP Racing 4-piston front, 2-piston rear
FUEL SYSTEM: Stock Honda
ELECTRONICS: Motec M400 ECU and student designed data acquisition
FUEL TYPE: 93 Octane
COOLING: Vertically mounted single core double pass radiator, 944 cfm fan
MPD: 10500 rpm
BSCD: 67mm bore / 42.5mm stroke / 599cc
MPT: 9000 rpm
SUSPENSION: Double unequal length A-arms, Ohlins TTX25 MkII dampers
FR/RR TRACK: 49in front, 49in rear
TIRE: Hoosier R25B 20.0x7.0-13
WEIGHT: 640 lbs with 150lb driver
OLWH: L: 3249mm / W: 1468mm / H: 1124mm
WHEELBASE: 61in
UNIQUE: Custom airfoils, custom CFRP steering wheel
FSAE Michigan 2013: 38th Overall
FSAE Lincoln 2013: 8th Overall
FSAE North 2013: 6th Overall
ENGINE: Honda CBR600 F4i
FRAME: 4130 Steel Space Frame
DRIVE: RWD
BRAKE: AP Racing 4-piston front, 2-piston rear
FUEL SYSTEM: Stock Honda
ELECTRONICS: Motec M400 ECU and student designed data acquisition
FUEL TYPE: 93 Octane
COOLING: Single core double pass radiator, 944 cfm fan
MPD: 10500 rpm
BSCD: 67mm bore / 42.5mm stroke / 599cc
MPT: 10500 rpm
SUSPENSION: Double unequal length A-arms, Ohlins TTX25 MkII dampers
FR/RR TRACK: 49in front, 49in rear
TIRE: Hoosier R25B 20.0x7.0-13
WEIGHT: 640 lbs with 150lb driver
OLWH: L: 3249mm / W: 1468mm / H: 1124mm
WHEELBASE: 66in
UNIQUE: Carbon fiber anti roll bands
FSAE Michigan 2012: 90th Overall
FSAE Lincoln 2012: 25th Overall
ENGINE: Honda CBR600 F4i
FRAME: 4130 Steel Space Frame
DRIVE: RWD
BRAKE: AP Racing 4-piston front, 2-piston rear
FUEL SYSTEM: Stock Honda
ELECTRONICS: Motec M400 ECU and student designed data acquisition
FUEL TYPE: 93 Octane
COOLING: Single core double pass radiator, 944 cfm fan
MPD: 10500 rpm
BSCD: 67mm bore / 42.5mm stroke / 599cc
MPT: 9000 rpm
SUSPENSION: Double unequal length A-arms, Ohlins TTX25 MkII dampers
FR/RR TRACK: 67mm bore / 42.5mm stroke / 599cc
TIRE: Hoosier R25B 20.0x7.0-13
WEIGHT: 640 lbs with 150lb driver
OLWH: L: 3249mm / W: 1468mm / H: 1124mm
WHEELBASE: 66in
UNIQUE: Carbon fiber anti roll bands
FSAE Michigan 2011: 42nd Overall
FSAE Lincoln 2011: 6th Overall
ENGINE: Honda CBR600 F4i
FRAME: 4130 Steel Space Frame
DRIVE: RWD
BRAKE: AP Racing calipers, A2 steel rotors
FUEL SYSTEM: Stock Honda
ELECTRONICS: Motec M400 ECU and custom LED wheel
FUEL TYPE: 93 Octane
COOLING: Air-to-water heat exchanger
MPD: 10500 rpm
BSCD: 67mm bore / 42.5mm stroke / 599cc
MPT: 9000 rpm
SUSPENSION: Double unequal length A-arms, Ohlins TTX25 MkII dampers
FR/RR TRACK: 67mm bore / 42.5mm stroke / 599cc
TIRE: Goodyear D2696 20.0x7.0-13
WEIGHT: 630 lbs with 150lb driver
OLWH: L: 3307mm / W: 1471mm / H: 1020mm
WHEELBASE: 66in
UNIQUE: Data display and switchgear in steering wheel
